Kaizen Electricals Private Limited have excellent design gives higher discharge & head due to efficient motor, extreme care has taken for selection of stator, rotor, winding wire & bearing. Silent Features of Kaizen Electricals Private Limited : Highly efficient, Low power consumption , Vibration free, Noiseless, Completely absence of suction trouble.
| Part Name | Material |
| Check valve housing | Cast Iron as per IS:210 |
| Neck Ring | Bronze / Nitrile Rubber |
| Bearing Bush | Nitrile Rubber |
| Pump Sleeve | S.S. with Hard Chrome |
| Impeller | S.S |
| Bowl | Cast Iron / S.S |
| Pump Shaft | S.S. – 410 |
| Suction Bush | L.T.B. – 4 |
| Couple | S.S. – 410 with key |
| Upper Housing | Cast Iron as per IS:21 |
| Winding | Polyester Insulated wire |
| Motor Shell | S.S.- 304 |
| Stator | C.R.N.O. Stampings |
| Rotor | C.R.N.O. + Copper |
| Bush Bearing | L.T.B – 4 |
| Flange | Mild Steel |
| Lower Housing | Cast Iron as per IS: 210 |
| Thrust Bearing | S.S. – 410 & Graphite Carbon |
| Motor Base | Cast Iron as per IS: 210 |
| Diffuser | P.P.O / C.I |
| Details | 200 Mm Water Field |
| Power Range | 7.5 HP to 45 HP – 3Ph. |
| Version | 380 – 415V, A.C. 50 Hz – 3 Ph. Permanently Connected and sealed PVC insulated 3 -core flat cable Permanently Connected and sealed PVC insulated 3 -core flat cable Speed |
| Speed | 2880 rpm. |
| Flow Rate | 300 lpm to 2400 lpm |
| Body | 12 mtrs to 230 mtrs |
| Outlet size in inches / mm | 75, 100,125, 150 mm. |
| Degree of Protection | IP 58 |
| Maximum Outer Diamete | 187 mm |
| Type of Duty | S1 (Continous) |
| Maximum Starts per hour | 12 times. |
| Method of startinb | 7.5 HP Direct. on line (D O L) 3 Ph. 10 to 45 HP – Star/Delta (S.D.) 3 Ph |
| Cable Connection | Permanently Connected and sealed PVC insulated 3 -core flat cable |
Clean, thin, non-aggresive, non-explosive, clear, cold fresh water without abresives, solid particle or fibres.
